Blackmagic Design ATEM SDI Switcher

$39.00
/
7 Day

Rental

Interested in purchasing?

Includes

  • ATEM SDI switcher
  • USB-C cable
  • Cat6A ethernet cable
  • AC adapter
  • Hard case

Resources

  • Manual
  • Blackmagic Design ATEM SDI Switcher

    The Blackmagic Design ATEM SDI Switcher is a 4-channel SDI switcher designed for live streaming and broadcasting HD video. Key features include:

    • 4-Channel live stream 3G-SDI switcher

    • 2-Channel digital audio mixer per source

    • Built in control panel

    • Includes upstream and downstream keyers

    Read More

    Q & A

  • Does this switcher support 4K video?
    • No, this switcher can only support video up to 1080p 60fps.

  • Does this switcher support HDMI?
  • Does this rental include any SDI cables?
    • No, but the recommended section of this page has a great selection, or you can browse here for more options.

  • Specifications

    Audio Type

    Switching

    Brand

    Blackmagic

    Inputs/Outputs

    Audio Inputs

    • Mic: (2) Stereo 3.5mm (1/8") mini phono
    Audio Outputs
    • None
    Video Inputs
    • (4) 3G-SDI
    Video Outputs
    • (2) 3G-SDI
    Additional Inputs/Outputs
    • Ethernet (RJ45) (PC control, direct streaming)
    • USB Type-C (firmware, webcam, USB drive recording)

    Item Type

    Switcher

    Physical

    Dimensions

    • 9.35 × 4.67 × 1.38″
    Weight
    • 23.9 oz

    Video Effects

    Transitions

    • Cut
    • Mix
    • Wipe
    • Dip
    • DVE: push, spin, squeeze, swoosh
    Filters
    • None
    Keying
    • Chroma Key
    • Luminance Key
    • Linear Key
    • Pattern Key

    Video Processing

    Bit Depth

    • 4:2:2 (YUV)
    • 10 bit
    Video Input Formats
    • 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98
    • 1080i: 60, 59.94, 50
    • 720p: 50.59.94

    Includes

    • ATEM SDI switcher
    • USB-C cable
    • Cat6A ethernet cable
    • AC adapter
    • Hard case

    Specifications

    Audio Type

    Switching

    Brand

    Blackmagic

    Inputs/Outputs

    Audio Inputs

    • Mic: (2) Stereo 3.5mm (1/8") mini phono
    Audio Outputs
    • None
    Video Inputs
    • (4) 3G-SDI
    Video Outputs
    • (2) 3G-SDI
    Additional Inputs/Outputs
    • Ethernet (RJ45) (PC control, direct streaming)
    • USB Type-C (firmware, webcam, USB drive recording)

    Item Type

    Switcher

    Physical

    Dimensions

    • 9.35 × 4.67 × 1.38″
    Weight
    • 23.9 oz

    Video Effects

    Transitions

    • Cut
    • Mix
    • Wipe
    • Dip
    • DVE: push, spin, squeeze, swoosh
    Filters
    • None
    Keying
    • Chroma Key
    • Luminance Key
    • Linear Key
    • Pattern Key

    Video Processing

    Bit Depth

    • 4:2:2 (YUV)
    • 10 bit
    Video Input Formats
    • 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98
    • 1080i: 60, 59.94, 50
    • 720p: 50.59.94

    Resources

  • Manual
  • Reviews

    See Reviews
