Magewell USB Fusion HDMI & USB Video Capture Device

$91.00
/
7 Day

Rental

Pricing Chart
Shipping Rates

Interested in purchasing?

Includes

  • Magewell USB Fusion
  • USB 3.0 A Male to Type C 18in
  • USB 3.1 Type-C to USB Female OTG Adapter Cable
  • AC Adapter

Resources

  • Quick Start Guide
  • Manual
  • Fusion App

    • Magewell USB Fusion HDMI & USB Video Capture Device

    The Magewell USB Fusion HDMI & USB Video Capture Device allows you to combine live video sources using it’s USB 3.0 and HDMI connectors. Key features include:

    • Two HDMI inputs and one USB webcam input with simultaneous support up to 1080p60

    • Multiple scene display modes, including single view, picture in picture, and side by side

    • USB 3.0 interface for data transfers, HDMI output for monitoring source or program

    • Driver-free video processing with zero CPU usage, Windows, Mac, and Linux compatible

    Read More

    Q & A

  • Does this rental include an HDMI cable?

    • No. If you don’t have a suitable HDMI cable, we offer a multitude of options for rental separately, and you can find them by sorting by the type needed here.

  • Does this device require a USB 3.0 capable computer?

    • Yes. This device will not function properly on a computer with only USB 2.0 ports.

    • Specifications

    Brand

    Magewell
    Dimensions

    7.3 × 4 × 1.2″
    Environmental

    Operating Temperature

    • 32 to 104°F
    Storage Temperature
    • -4 to 158°F
    Operating Humidity
    • 5 to 90% (Non-Condensing)
    Hardware

    RAM

    • 32 GB
    Wi-Fi
    • Wi-Fi 6 (802.11ax)
    OS Compatibility
    • Windows 7 or Later
    • Linux 2.6.35 or Later
    • macOS 10.12 or Later
      *As of July, 2022: Check with manufacturer for the most up-to-date compatibility
    IP Streaming

    Video IP Encoding

    • H.264, MP4: x 1080 to x at 60p
    Video IP Decoding
    • H.264, H.265: 3264 × 2448
    Audio IP Encoding
    • MP3: 16-Bit / 48 kHz
    Inputs/Outputs

    Video Inputs

    • 2 x HDMI (HDMI 1.4) Female
    • 1 x USB-A Female
    Audio Inputs
    • 1 × 1/8" / 3.5 mm TRS Stereo Female
    • 1 × 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Female
    Video Outputs
    • 1 x USB-C Female
    • 1 x HDMI (HDMI 1.4) Female
    Audio Outputs
    • 1 × 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Female
    Other I/O
    • 1 x RJ45 LAN Input
    Expansion Slots
    • None
    Input Video Format
  • HDMI (8-Bit 4:4:4/4:2:2 RGB, YUV, YCC)
    • 1080p 60 fps
    USB-A
    • 1080p 60 fps
    Output Video Format
  • USB-A (8-Bit 4:4:4/4:2:2 YUV)
    • 1080p 15/30/60 fps
    • 720p 15/30/60 fps
  • VGA (640 × 480)
    • 15/30/60 fps
    Embedded Audio
    • HDMI/USB: 2-Channel

    		•
    Item Type

    Monitoring
    Monitoring Type

    Accessories
    See All

    Includes

    • Magewell USB Fusion
    • USB 3.0 A Male to Type C 18in
    • USB 3.1 Type-C to USB Female OTG Adapter Cable
    • AC Adapter

    Specifications

    Brand

    Magewell
    Dimensions

    7.3 × 4 × 1.2″
    Environmental

    Operating Temperature

    • 32 to 104°F
    Storage Temperature
    • -4 to 158°F
    Operating Humidity
    • 5 to 90% (Non-Condensing)
    Hardware

    RAM

    • 32 GB
    Wi-Fi
    • Wi-Fi 6 (802.11ax)
    OS Compatibility
    • Windows 7 or Later
    • Linux 2.6.35 or Later
    • macOS 10.12 or Later
      *As of July, 2022: Check with manufacturer for the most up-to-date compatibility
    IP Streaming

    Video IP Encoding

    • H.264, MP4: x 1080 to x at 60p
    Video IP Decoding
    • H.264, H.265: 3264 × 2448
    Audio IP Encoding
    • MP3: 16-Bit / 48 kHz
    Inputs/Outputs

    Video Inputs

    • 2 x HDMI (HDMI 1.4) Female
    • 1 x USB-A Female
    Audio Inputs
    • 1 × 1/8" / 3.5 mm TRS Stereo Female
    • 1 × 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Female
    Video Outputs
    • 1 x USB-C Female
    • 1 x HDMI (HDMI 1.4) Female
    Audio Outputs
    • 1 × 1/8" / 3.5 mm TRRS Headphone/Microphone Stereo Female
    Other I/O
    • 1 x RJ45 LAN Input
    Expansion Slots
    • None
    Input Video Format
  • HDMI (8-Bit 4:4:4/4:2:2 RGB, YUV, YCC)
    • 1080p 60 fps
    USB-A
    • 1080p 60 fps
    Output Video Format
  • USB-A (8-Bit 4:4:4/4:2:2 YUV)
    • 1080p 15/30/60 fps
    • 720p 15/30/60 fps
  • VGA (640 × 480)
    • 15/30/60 fps
    Embedded Audio
    • HDMI/USB: 2-Channel

    		•
    Item Type

    Monitoring
    Monitoring Type

    Accessories
    See All

    Resources

  • Quick Start Guide
  • Manual
  • Fusion App

    • Reviews

    See Reviews
