SmallHD 7-inch 702 OLED HDMI / SDI Monitor

$144.00
/
7 Day

Rental

Interested in purchasing?

Learn More

Includes

Does not include HDMI / SDI cables.

Resources

  • Manual
  • 138830223620
    848222334899283534562325740101231418985081543827160052237721946433645503618350783858290662863027568517468996637331527075

    SmallHD 7-inch 702 OLED HDMI / SDI Monitor

    The SmallHD 7-inch 702 OLED HDMI / SDI Monitor is a feature-rich OLED monitor perfect for use with an array of camera types. Key features include:

    • High-definition 7.7-inch, 1280 × 800 OLED monitor

    • 300-nit brightness rating; 160° viewing angle

    • HD scopes, exposure tools, frame guides, intuitive GUI

    • HDMI / SDI Cross-Conversion

    Read More

    Q & A

  • Why can't I see my battery percentage?
    • There is a bug in the latest firmware version (3.3.7) that does not allow battery percentage to be viewed. We will update our monitors to the next stable firmware release when it is available.

  • Is an AC adapter included with the rental?
    • This monitor does not come standard with an AC adapter or big-battery solution. However, we do offer both options as a separate rental item. See the Recommended section on the left-hand side of this page for options.

  • How is this monitor powered?
    • We include two Canon LP-E6 batteries with the monitor.

    • While this monitor will accept Sony L-series batteries, we don’t recommend using them because they’re unreliable with 700-series monitors.

  • Is this monitor compatible with Paralinx and ikan products?
    • This monitor is not compatible with Paralinx and ikan products.

  • Does this rental include HDMI or SDI cables?
    • This rental doesn’t include HDMI or SDI cables. If you need HDMI/SDI cables, you can find them here.

  • Specifications

    Brand

    SmallHD

    Display

    Screen Type

    • 7.7“ OLED
    Resolution
    • 1280 × 800
    Pixel Density
    • 191 PPI
    Bit Depth
    • 8-bit display/10-bit color processing
    Brightness
    • 300 nits

    Inputs/Outputs

    Video Inputs

    • 1x 3G/HD-SDI
    • 1x HDMI
    Video Outputs
    • 1x HD-SDI
    • 1x HDMI
    3G-SDI Input/Output Formats
    • All at 8-bit
    • 1080p: 50/59.94/60
    • 1080i: 100/119.88/120
    HD-SDI Input/Output Formats
    • RGB/YCC 4:2:2/4:4:4
    • 1080p: 23.98/24/25/30/50/59.94/60
    • 1080pSF: 23.98/24/25/29.97
    • 1080i: 50/59.94/60
    • 720p: 50/59.94/60
    HDMI Input/Output Formats
    • 8/10/12-bit color support
    • 1080p: 23.98/24/25/30/50/60
    • 1080pSF: 23.98/24/25/30
    • 1080i: 50/59.94/60
    • 720p: 50/59.94/60
    Additional Inputs/Outputs
    • Micro USB

    Item Type

    Monitoring

    Monitoring Type

    Monitor

    Physical

    Dimensions

    • 8.25” x 5.2” x 1.1”
    Weight
    • 1.6 lbs.
    Accessory Mounts
    • 7x ¼-20 thread points

    Power Supply

    Battery Compatibility

    • Dual Canon LP-E6 battery trays
    • Dual Sony NP-F770/970 (not recommended)
    Additional Power Compatibility
    • SmallHD AC adapter for 500/700 Series
    • SmallHD D-Tap with LP-E6 coupler

    Includes

    Does not include HDMI / SDI cables.

    Specifications

    Brand

    SmallHD

    Display

    Screen Type

    • 7.7“ OLED
    Resolution
    • 1280 × 800
    Pixel Density
    • 191 PPI
    Bit Depth
    • 8-bit display/10-bit color processing
    Brightness
    • 300 nits

    Inputs/Outputs

    Video Inputs

    • 1x 3G/HD-SDI
    • 1x HDMI
    Video Outputs
    • 1x HD-SDI
    • 1x HDMI
    3G-SDI Input/Output Formats
    • All at 8-bit
    • 1080p: 50/59.94/60
    • 1080i: 100/119.88/120
    HD-SDI Input/Output Formats
    • RGB/YCC 4:2:2/4:4:4
    • 1080p: 23.98/24/25/30/50/59.94/60
    • 1080pSF: 23.98/24/25/29.97
    • 1080i: 50/59.94/60
    • 720p: 50/59.94/60
    HDMI Input/Output Formats
    • 8/10/12-bit color support
    • 1080p: 23.98/24/25/30/50/60
    • 1080pSF: 23.98/24/25/30
    • 1080i: 50/59.94/60
    • 720p: 50/59.94/60
    Additional Inputs/Outputs
    • Micro USB

    Item Type

    Monitoring

    Monitoring Type

    Monitor

    Physical

    Dimensions

    • 8.25” x 5.2” x 1.1”
    Weight
    • 1.6 lbs.
    Accessory Mounts
    • 7x ¼-20 thread points

    Power Supply

    Battery Compatibility

    • Dual Canon LP-E6 battery trays
    • Dual Sony NP-F770/970 (not recommended)
    Additional Power Compatibility
    • SmallHD AC adapter for 500/700 Series
    • SmallHD D-Tap with LP-E6 coupler
