Whirlwind THS 5 Talkback Headphone Box

$53.00

/

7 Day

Rental

Arrival Date

Return Date

Includes

Whirlwind THS 5 Talkback Headphone Box
Porta Brace PB-B812 Stuff Sack
Triad WAU120-1000 12V Barrel AC Adapter

Resources

Recommended:

Whirlwind THS 5 Talkback Headphone Box

The Whirlwind THS 5 Talkback Headphone Box is a lightweight and compact solution for sports commentary and announcing. Key features include:

XLR, 1/4", and 3.5mm connections
Individual volume and pan controls
36V Phantom power for condenser mics
Primary headphone volume adjusts mix

Q & A

Does this rental include any cables, headphones, or microphones?

No. All accessories for this console are available separately, and can be found in the Recommended section on your screen.

Specifications

Audio Type	Mixer
Brand	Whirlwind
Dimensions	8.0 × 5.0 × 2.5″
Frequency Response	Mic In to Mic Out ±0.2 dB 20 Hz to 16 kHz Mic In to Talkback Out @ 40 dB Gain ±0.9 dB 20 Hz to 20 kHz Input 1 & 2 to Headphone Out ±1.3 dB 20 Hz to 10 kHz Mic In to Headphone Out @ 40 dB Gain ±2.3 dB 20 Hz to 12.5 kHz Mic In to Talkback Out @ 0 dB Gain -40 dBV Level ±1.6 dB 20 Hz to 20 kHz Mic In to Talkback Out @ 0 dB Gain -10 dBV Level ±0.6 dB 20 Hz to 20 kHz
Item Type	Audio
Mfr. Model Number	#THS5
Noise	Mic In to Mic Out < -118 dBV Mic In to Talkback Out @ 40 dB Gain < -75 dBV Mic In to Talkback Out @ 0 dB Gain < -112 dBV Input 1 & 2 to Headphone Out @ 0 dB Gain < -103 dBV Mic in to Headphone Out @ Unity Gain < -101 dBV Mic in to Headphone Out @ 40 dB Gain < -77.6 dBV
Power	Power Requirements 12 VAC 1000 mA Power Draw At Secondary of 12 VAC Transformer: 0.410 A min to 0.641 A max At 120 VAC Line: 0.058 A min to 0.090 A max
Supported I/O	3.5mm and XLR
THD+N	Mic In to Mic Out @ -40 dBV <0.015% 20 Hz to 20 kHz Mic In to Talkback Out @ 40 dB Gain <0.02% 80 Hz to 4 kHz, <0.04% 50 Hz to 20 kHz Mic In to Headphone Out @ 40 dB Gain Input Level –40 dBV <0.02% 20 Hz to 20 kHz Mic In to Mic Out @ 0 dBV <0.0075% 20 Hz to 20 kHz Mic In to Talkback Out @ 40 dB Gain -40 dBV Input Level <0.03% 50 Hz to 20 kHz Input 1 & 2 to Headphone Out with 0 dBV In and Out <0.02% 20 Hz to 20 kHz Mic In to Talkback Out <0.009% 63 Hz to 20 kHz
Weather Sealing	No
Weight	2.9 lb
Wireless Capability	No

Includes

Whirlwind THS 5 Talkback Headphone Box
Porta Brace PB-B812 Stuff Sack
Triad WAU120-1000 12V Barrel AC Adapter

Specifications

Audio Type	Mixer
Brand	Whirlwind
Dimensions	8.0 × 5.0 × 2.5″
Frequency Response	Mic In to Mic Out ±0.2 dB 20 Hz to 16 kHz Mic In to Talkback Out @ 40 dB Gain ±0.9 dB 20 Hz to 20 kHz Input 1 & 2 to Headphone Out ±1.3 dB 20 Hz to 10 kHz Mic In to Headphone Out @ 40 dB Gain ±2.3 dB 20 Hz to 12.5 kHz Mic In to Talkback Out @ 0 dB Gain -40 dBV Level ±1.6 dB 20 Hz to 20 kHz Mic In to Talkback Out @ 0 dB Gain -10 dBV Level ±0.6 dB 20 Hz to 20 kHz
Item Type	Audio
Mfr. Model Number	#THS5
Noise	Mic In to Mic Out < -118 dBV Mic In to Talkback Out @ 40 dB Gain < -75 dBV Mic In to Talkback Out @ 0 dB Gain < -112 dBV Input 1 & 2 to Headphone Out @ 0 dB Gain < -103 dBV Mic in to Headphone Out @ Unity Gain < -101 dBV Mic in to Headphone Out @ 40 dB Gain < -77.6 dBV
Power	Power Requirements 12 VAC 1000 mA Power Draw At Secondary of 12 VAC Transformer: 0.410 A min to 0.641 A max At 120 VAC Line: 0.058 A min to 0.090 A max
Supported I/O	3.5mm and XLR
THD+N	Mic In to Mic Out @ -40 dBV <0.015% 20 Hz to 20 kHz Mic In to Talkback Out @ 40 dB Gain <0.02% 80 Hz to 4 kHz, <0.04% 50 Hz to 20 kHz Mic In to Headphone Out @ 40 dB Gain Input Level –40 dBV <0.02% 20 Hz to 20 kHz Mic In to Mic Out @ 0 dBV <0.0075% 20 Hz to 20 kHz Mic In to Talkback Out @ 40 dB Gain -40 dBV Input Level <0.03% 50 Hz to 20 kHz Input 1 & 2 to Headphone Out with 0 dBV In and Out <0.02% 20 Hz to 20 kHz Mic In to Talkback Out <0.009% 63 Hz to 20 kHz
Weather Sealing	No
Weight	2.9 lb
Wireless Capability	No
