RED SCARLET-W Brain

$725.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Learn More

Includes

RED SCARLET-W Brain w/integrated media bay
AC Power Adapter (DSMC) w/power cable
DSMC2 Base Expander
DSMC2 Lemo A Adapter
DSMC2 Standard OLPF (installed)

Resources

Operation Guide

Sample R3D Files

Red Tools

RED SCARLET-W Brain

The RED Scarlet-W Brain is the smaller, more affordable alternative to the RED WEAPON Magnesium and an update to the RED Scarlet-X Dragon Brain. Key features include:

Super 35mm RED Dragon sensor
High dynamic range, advanced color science, RAW recording
Interchangeable optical low-pass filters
Compact build and intuitive layout

Q & A

Are there any known power compatibility issues with this brain?

Wooden Cable-less battery plates used with DSMC2 brains running firmware version 7.1 or newer require a firmware update to the plate before it can be recognized as a compatible module by the camera.
We’ve updated our copies in-house so if you rent a DSMC2 brain and cable-less plate from us, you’re all set! If you source a cable-less plate from somewhere else, you can go here for instructions on how to update the plate yourself.

What do I need to operate this camera?

At minimum, you’ll need these items to operate this camera: a RED DSMC Lens Mount; a RED Mini-Mag SSD; a RED Mini-Mag Station; and a menu-interface solution such as the RED DSMC2 Sidekick (external monitor required for live view), a RED Touch LCD, or a DSMC2 Touch LCD.

Are REDMAG SSDs compatible with this camera?

REDMAG SSDs aren’t compatible with this camera.

Do I need a certificate of insurance or a deposit to rent this item?

You’ll need a certificate of insurance, LensCap+, or a deposit to rent this item.

Specifications

Audio	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz and Optional 2 additional channels with DSMC2 expander module, uncompressed, 24-bit 48 kHz
Brand	RED
Camcorder Type	Cinema
Camera Type	Camcorder
DC Input	Proprietary Connector
Data Rates	Up to 170 MB/s using RED MINI-MAG
Dynamic Range	16.5+ stops
Inputs/Outputs	Video Outputs HD-SDI Output BNC (10-bit) HDMI Output Type A
Item Type	Camera
Maximum Frame Rates	Full Format (1.9:1): 5K (5120 × 2700): 50 fps 4K (4096 × 2160): 120 fps 3K (3072 × 1620): 150 fps 2K (2048 × 1080): 240 fps Scope (2.4:1): 5K (5120 × 2160): 60 fps 4K (4096 × 1782): 150 fps 3K (3072 × 1296): 200 fps 2K (2048 × 864): 300 fps *REDCODE values and max frame rates may vary based on selected acquisition format, aspect ratio, project time base, and SSD.
Memory Type	Red Mini-Mag SSD
Recording Formats	REDCODE RAW (available compression ratios): 4:1-22:1 REDCODE for 5K Full Format (5120 × 2700) at 24 fps 7:1-22:1 REDCODE for 6K Full Format (5120 × 2700) at 50 fps 3:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 24 fps 6:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 60 fps Compression ratios and resolutions are limited to the recording data rate limitations. Apple ProRes:* 4096 × 2160: ProRes 422 LT/422/422 HQ up to 29.97 fps 2048 × 1080: ProRes 422 LT/422/422 HQ/4444/4444 XQ up to 120 fps AVID DNx: 4096 × 2160: DNxHR 8-bit SQ/LB up to 29.97 fps 1920 × 1080: DNxHD 8-bit HQ/SQ/LB up to 60 fps
Recording Time	5K (5120 × 2700) at 24 fps and 11:1 REDCODE: Approximately 0.34GB/Min 5K (5120 × 2700) at 48 fps and 14:1 REDCODE: Approximately 0.21GB/Min 4.5K 2.4:1 (4608 × 1944) at 120 fps and 15:1 REDCODE: Approximately 0.14GB/Min
Resolutions	5K (5120 X 2700) 4.5K (4608×2160) 4K (4096 × 2160) 3K (3072 × 2160) 2K (2048 × 1080)
Sensor Size	25.6 mm x 13.5 mm (Diagonal: 28.9 mm)
Sensor Type	RED DRAGON 13.8 MP Super 35mm CMOS
Weight	3.5 lbs (BRAIN with Integrated Media Bay)

See All

Includes

RED SCARLET-W Brain w/integrated media bay
AC Power Adapter (DSMC) w/power cable
DSMC2 Base Expander
DSMC2 Lemo A Adapter
DSMC2 Standard OLPF (installed)

Specifications

Audio	Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz and Optional 2 additional channels with DSMC2 expander module, uncompressed, 24-bit 48 kHz
Brand	RED
Camcorder Type	Cinema
Camera Type	Camcorder
DC Input	Proprietary Connector
Data Rates	Up to 170 MB/s using RED MINI-MAG
Dynamic Range	16.5+ stops
Inputs/Outputs	Video Outputs HD-SDI Output BNC (10-bit) HDMI Output Type A
Item Type	Camera
Maximum Frame Rates	Full Format (1.9:1): 5K (5120 × 2700): 50 fps 4K (4096 × 2160): 120 fps 3K (3072 × 1620): 150 fps 2K (2048 × 1080): 240 fps Scope (2.4:1): 5K (5120 × 2160): 60 fps 4K (4096 × 1782): 150 fps 3K (3072 × 1296): 200 fps 2K (2048 × 864): 300 fps *REDCODE values and max frame rates may vary based on selected acquisition format, aspect ratio, project time base, and SSD.
Memory Type	Red Mini-Mag SSD
Recording Formats	REDCODE RAW (available compression ratios): 4:1-22:1 REDCODE for 5K Full Format (5120 × 2700) at 24 fps 7:1-22:1 REDCODE for 6K Full Format (5120 × 2700) at 50 fps 3:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 24 fps 6:1-22:1 REDCODE for 4K Full Format (4096 × 2160) at 60 fps Compression ratios and resolutions are limited to the recording data rate limitations. Apple ProRes:* 4096 × 2160: ProRes 422 LT/422/422 HQ up to 29.97 fps 2048 × 1080: ProRes 422 LT/422/422 HQ/4444/4444 XQ up to 120 fps AVID DNx: 4096 × 2160: DNxHR 8-bit SQ/LB up to 29.97 fps 1920 × 1080: DNxHD 8-bit HQ/SQ/LB up to 60 fps
Recording Time	5K (5120 × 2700) at 24 fps and 11:1 REDCODE: Approximately 0.34GB/Min 5K (5120 × 2700) at 48 fps and 14:1 REDCODE: Approximately 0.21GB/Min 4.5K 2.4:1 (4608 × 1944) at 120 fps and 15:1 REDCODE: Approximately 0.14GB/Min
Resolutions	5K (5120 X 2700) 4.5K (4608×2160) 4K (4096 × 2160) 3K (3072 × 2160) 2K (2048 × 1080)
Sensor Size	25.6 mm x 13.5 mm (Diagonal: 28.9 mm)
Sensor Type	RED DRAGON 13.8 MP Super 35mm CMOS
Weight	3.5 lbs (BRAIN with Integrated Media Bay)

See All

Resources

Operation Guide

Sample R3D Files

Red Tools

$725.00

7 Day

Rental

Arrival Date

Return Date

Pricing Chart

Shipping Rates

Interested in purchasing?

Learn More

Includes

RED SCARLET-W Brain w/integrated media bay
AC Power Adapter (DSMC) w/power cable
DSMC2 Base Expander
DSMC2 Lemo A Adapter
DSMC2 Standard OLPF (installed)

Resources

Operation Guide

Sample R3D Files

Red Tools

Rental Period	Lenscap+	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$116.00	$508.00	$624.00	$208.00
4 days	$124.00	$544.00	$668.00	$167.00
7 days	$165.00	$725.00	$890.00	$127.14
10 days	$223.00	$979.00	$1202.00	$120.20
14 days	$289.00	$1269.00	$1558.00	$111.29
21 days	$388.00	$1704.00	$2092.00	$99.62
30 days	$487.00	$2139.00	$2626.00	$87.53
45 days	$635.00	$2791.00	$3426.00	$76.13
60 days	$743.00	$3263.00	$4006.00	$66.77
90 days	$957.00	$4205.00	$5162.00	$57.36

Rental Period	Lenscap	Rental Price	Total Price	Price Per Day (Approx.)
3 days	$77.00	$508.00	$585.00	$195.00
4 days	$83.00	$544.00	$627.00	$156.75
7 days	$110.00	$725.00	$835.00	$119.29
10 days	$149.00	$979.00	$1128.00	$112.80
14 days	$193.00	$1269.00	$1462.00	$104.43
21 days	$259.00	$1704.00	$1963.00	$93.48
30 days	$325.00	$2139.00	$2464.00	$82.13
45 days	$424.00	$2791.00	$3215.00	$71.44
60 days	$495.00	$3263.00	$3758.00	$62.63
90 days	$638.00	$4205.00	$4843.00	$53.81

Rental Period	Rental Price	Price Per Day (Approx.)
3 days	$508.00	$169.33
4 days	$544.00	$136.00
7 days	$725.00	$103.57
10 days	$979.00	$97.90
14 days	$1269.00	$90.64
21 days	$1704.00	$81.14
30 days	$2139.00	$71.30
45 days	$2791.00	$62.02
60 days	$3263.00	$54.38
90 days	$4205.00	$46.72
