Sound Devices A20-Mini Wireless Transmitter and Recorder

Includes

  • A20-Mini bodypack
  • SMA antenna (470 – 548 MHz)
  • Holster
  • Hard case

Sound Devices A20-Mini Wireless Transmitter and Recorder

While we no longer rent this product, here’s a link to our current selections.

  • 48 kHz, 32-bit float WAV recording with 80 hours of internal storage

  • Control all recorder functions via 2.4 GHz Bluetooth

  • Rated for up to 3.5 hours of operating time on fully charged batteries

  • Lav microphone not included

Read More

Q & A

  • Can this be used as a timecode generator?
    • You’ll need your own LEMO 5-pin to USB Type C or BNC to USB Type C cable to take advantage of this feature.

  • Do you rent a wireless receiver for this unit?
    • The transmitter portion of this wireless transmitter and recorder works with the Sound Devices A10 system, but we do not rent a compatible wireless receiver for this body pack at this time.

  • Does this use any external media?
    • No. This unit can only record to 64GB of internal memory, but that will allow for 80 hours of recording before needing to be offloaded.

  • Specifications

    Brand

    Sound Devices

    Inputs/Outputs

    Lavalier Input

    • 3-pin LEMO
    • 5 V bias power
    Headphone Out
    • None
    USB Type C
    • Charging
    • Host Connection

    Item Type

    Wireless Audio and Recorders

    Performance

    Frequency Response

    • 10 Hz to 20 kHz ±1 dB
    Dynamic Range
    • 130 dB

    Physical

    Dimensions

    • 1.9 × 3 × 0.7″
    Weight
    • 1.8 oz

    Power

    Battery Compatibility

    Operation Time
    • ~3-5 hr (battery dependent)
    Charing Time

      Recording

      Tracks

      • Single
      Sample Rate
      • 48 kHz
      Bit-Depth
      • 32-bit Float
      File Formats
      • WAV
      Media Type
      • 64GB (internal)
      Recording Time
      • 80 hours (32-bit Float)

      Includes

      • A20-Mini bodypack
      • SMA antenna (470 – 548 MHz)
      • Holster
      • Hard case

      Specifications

      Brand

      Sound Devices

      Inputs/Outputs

      Lavalier Input

      • 3-pin LEMO
      • 5 V bias power
      Headphone Out
      • None
      USB Type C
      • Charging
      • Host Connection

      Item Type

      Wireless Audio and Recorders

      Performance

      Frequency Response

      • 10 Hz to 20 kHz ±1 dB
      Dynamic Range
      • 130 dB

      Physical

      Dimensions

      • 1.9 × 3 × 0.7″
      Weight
      • 1.8 oz

      Power

      Battery Compatibility

      Operation Time
      • ~3-5 hr (battery dependent)
      Charing Time

        Recording

        Tracks

        • Single
        Sample Rate
        • 48 kHz
        Bit-Depth
        • 32-bit Float
        File Formats
        • WAV
        Media Type
        • 64GB (internal)
        Recording Time
        • 80 hours (32-bit Float)
