SlingStudio CameraLink

Includes

  • SlingStudio CameraLink
  • Hot shoe to 1/4"-20 adapter
  • USB Charger – Type-A 9V/2A 1-Port QC 3.0
  • USB cable

Resources

  • Quick Start Guide
  • SlingStudio CameraLink

    While this SlingStudio transmitter option is no longer available for rent, here’s a link to our current selections.

    • Add-on Wi-Fi video transmitter for SlingStudio

    • Supports formats up to 1080p60 at 30 Mbps

    • Up to two hours of battery life

    • Shoe mount included

    Read More

    Q & A

  • How many CameraLinks can be connected to one SlingStudio Hub?
    • Up to 10 CameraLinks or mobile devices can be simultaneously connected to one SlingStudio Hub. However, only four of those can be actively switched at any given time.

  • Will I need anything else?
  • Specifications

    Brand

    SlingStudio

    Item Type

    Monitoring

    Monitoring Type

    Wireless

    Physical

    Dimensions (WxHxL)

    • 4.6” x 2.9” x 1.4”
    Weight
    • 0.6 lb.

    Power Supply

    Battery Type

    • Lithium-ion
    • 11.47 Wh (3.7V DC, 3100 mAh)
    Battery Life
    • Operation Time: Approximately 100 minutes
    • Recharge Time: Approximately 3.5 hours
    Power Input
    • USB Micro-B

    Video Processing

    Video Input

    • HDMI Type-D (Micro HDMI) (embedded audio)
    Supported Formats
    • Video: H.264, 4:2:0
    • Audio: AAC-LC, 2-Ch, 16-bit/48 kHz, up to 320 kbps
    Supported Video Modes
    • 1080p60/1080i60 up to 30 Mbps
    • 1080p30 up to 16 Mbps
    • 720p60 up to 16 Mbps
    • 720p30 up to 4 Mbps

    Wireless

    Frequency

    • 5 GHz
    • 802.11 ac
    Transmission Range
    • Up to 300’ / 100M line of sight

    Includes

    • SlingStudio CameraLink
    • Hot shoe to 1/4"-20 adapter
    • USB Charger – Type-A 9V/2A 1-Port QC 3.0
    • USB cable

    Specifications

    Brand

    SlingStudio

    Item Type

    Monitoring

    Monitoring Type

    Wireless

    Physical

    Dimensions (WxHxL)

    • 4.6” x 2.9” x 1.4”
    Weight
    • 0.6 lb.

    Power Supply

    Battery Type

    • Lithium-ion
    • 11.47 Wh (3.7V DC, 3100 mAh)
    Battery Life
    • Operation Time: Approximately 100 minutes
    • Recharge Time: Approximately 3.5 hours
    Power Input
    • USB Micro-B

    Video Processing

    Video Input

    • HDMI Type-D (Micro HDMI) (embedded audio)
    Supported Formats
    • Video: H.264, 4:2:0
    • Audio: AAC-LC, 2-Ch, 16-bit/48 kHz, up to 320 kbps
    Supported Video Modes
    • 1080p60/1080i60 up to 30 Mbps
    • 1080p30 up to 16 Mbps
    • 720p60 up to 16 Mbps
    • 720p30 up to 4 Mbps

    Wireless

    Frequency

    • 5 GHz
    • 802.11 ac
    Transmission Range
    • Up to 300’ / 100M line of sight
